Shimano Ocea Jigger
DESCRIPTION
Fusing Shimano's most advanced manufacturing capabilities with the needs of anglers, the Ocea Jigger is a flagship-level star drag jigging reel. Boasting Shimano’s Infinity Drive technology, Ocea Jigger offers paramount cranking power by reducing friction between the pinion gear and spool shaft, greatly improving rotational torque. Combined with MicroModule gearing, anglers will experience unmatched gear feeling. X-Protect enhances durability and water resistance by utilizing a water repellant coating and a labyrinth construction to funnel water away from key wear parts. The adjustable, two-position, long-crank handle combined with the Spool Lock allow anglers to more safely break off snagged lures. The Auto-Clutch easily engages the reel out of free spool to react to quick bites, and Shimano’s Exciting Drag Sound alerts anglers when they are in jeopardy of pulling hooks or breaking off. The bottom line: the Ocea Jigger is packed with features that add up to provide all-day jigging ease and comfort.
FEATURES
HAGANE is a Shimano reel design concept created to withstand continual use and extreme abuse. HAGANE is an innovation with built-in toughness and durability that works alongside Shimano's precision engineering. HAGANE is for all anglers.
The MicroModule Gear system creates a smooth retrieve by utilizing smaller teeth to increase the number of contact points between the drive gear and pinion gear. Ultimately, this produces a more efficient gear train with less of a gear feel.
The HAGANE Body is a metal reel body with high rigidity. The body rigidity and impact resistance virtually eliminates body flexing on the reel while fighting fish. The result transforms the angler's actions directly into cranking power, increasing efficiency through strength.
Infinity Drive technology is an advanced structure that produces more powerful and exceptionally light winding within conventional and low-profile reels. This innovative design supports the pinion gear with the spool shaft rather than supporting the pinion gear with a bearing on the spool side. Infinity Drive within low-profile and conventional reels also optimizes the support distance and pinion gear thickness to achieve high support rigidity so that anglers can actively wind under heavy loads without compromising gear strength.
X PROTECT provides high-level water resistance to the inside bearing of drive gear shaft with waterproof construction.
S-Compact Body allows for all-day comfort and improved fishability by making the palming side plate up to 25% smaller than the A-Side plate.
The Cross Carbon Drag material provides a wider range of drag settings compared to traditional drag materials. The Cross Carbon Drag provides the smoothest Shimano drag performance ever while providing anglers with increased durability.
Exciting Drag Sound technology enables drag sound on a baitcasting reel without using the function of a rattle or clicker. This ultimately makes it easy for an angler to determine whether a fish is pulling drag and provides an advantage during the fight.
S A-RB bearings are put through the same process as Shimano’s A-RB bearings but feature shields on both sides of the bearings. These shields reduce the possibility of salt or sand inhibiting rotation of the bearing.
A highly rigid and strong cold-forged long crank handle comes standard, and its synergistic effect with the HAGANE body enables direct reeling performance without power loss.
Highly rigid clutch lever with improved operability
The clutch section features a newly shaped clutch lever that is cold-forged and beaten to achieve not only a high quality feel but also operability that surpasses that of previous models.
Large-diameter gears boasting toughness
The large-diameter drive gear, which supports the drive unit, is made of ultra-high-strength brass material and designed to be massive and highly precise. There is no compromise in strength.
Special surface treatment improves durability
In the NEW OCEA JIGGER, the pinion gear has been given a special surface treatment to improve salt resistance. Significantly contributes to improved clutch durability.
Internal parts with high strength & corrosion resistance
Stainless steel material with excellent rigidity and corrosion resistance is used in every corner of the washers and other internal parts. Durability is carried through to every detail.
Carbon cross washer is used for both good sliding performance and high durability. It contributes to silky drag performance.
Adjustment can be made while gripping the handle knob. The large diameter of the knob makes it easy to make fine adjustments when loosening the drag, making it easier to maintain the proper drag force when dealing with large fish.
A FALL LEVER assembly of OCEA JIGGER F CUSTOM No.2000 can be attached.
A mechanism that completely locks the spool and locks reversal. This mechanism provides peace of mind in the event of root entrapment.
Achieved 11 times greater reversal strength than the 03 OCEA JIGGER 4000. Durability is also improved by waterproof sealing to reduce water penetration into the drive gear shaft.
The clutch uses an auto-return system that returns in conjunction with the handle. This eliminates the time lag between the bottom touch and the start of reeling, ensuring that the angler never misses a chance to strike immediately after the bait hits the bottom.
SPECIFICATIONS
#OCEAJG1500HG
Model: OCEAJG1500HG
#OCEAJG1500PG
Model: OCEAJG1500PG
#OCEAJG2000NRHG
Model: OCEAJG2000NRHG
#OCEAJG2000NRPG
Model: OCEAJG2000NRPG
#OCEAJG4000
Model: OCEAJG4000
#OCEAJG4000HG
Model: OCEAJG4000HG
#ALL
| Bearings |
#OCEAJG1500HG #OCEAJG1500PG #OCEAJG2000NRHG #OCEAJG2000NRPG9 (8BB; 1RB) #OCEAJG4000 #OCEAJG4000HG7 (6BB; 1RB) |
| Gear Ratio |
#OCEAJG1500HG6.4:1 #OCEAJG1500PG5.1:1 #OCEAJG2000NRHG6.2:1 #OCEAJG2000NRPG5.1:1 #OCEAJG40004.4:1 #OCEAJG4000HG5.1:1 |
| Line Per Handle Turn |
#OCEAJG1500HG39" #OCEAJG1500PG31" #OCEAJG2000NRHG46" #OCEAJG2000NRPG38" #OCEAJG400040” #OCEAJG4000HG46” |
| Weight |
#OCEAJG1500HG14.3 oz #OCEAJG1500PG14.3 oz #OCEAJG2000NRHG21.0 oz #OCEAJG2000NRPG21.0 oz #OCEAJG400027.7 oz #OCEAJG4000HG27.9 oz |
|
Line Capacity (Lb Test/Yards) |
#OCEAJG1500HGPower Pro: 40/300, 50/250, 65/180 #OCEAJG1500PGPower Pro: 40/300, 50/250, 65/180 #OCEAJG2000NRHGPower Pro: 40/400, 50/340, 65/250 #OCEAJG2000NRPGPower Pro: 40/400, 50/340, 65/250 #OCEAJG4000Power Pro: 50/740, 65/540, 80/450 #OCEAJG4000HGPower Pro: 50/740, 65/540, 80/450 |
| Max Drag |
#OCEAJG1500HG15 Lbs #OCEAJG1500PG17 Lbs #OCEAJG2000NRHG22 Lbs #OCEAJG2000NRPG22 Lbs #OCEAJG400040 Lbs #OCEAJG4000HG40 Lbs |
| Retrieve | Right |
